Diagnostic Prior to Rig Deputation Enabled ~$900,000 in Revenue Over 6 months and Saved ~$20,000 Due to Extension of Overhaul by 2000 hrs


Engine Health Diagnostics Prior to Overhaul enabled ~$900,000 in Revenue over six months & saved ~$20,000 due to extension of overhaul by 2000 hrs


Industry Segment

Oil and Gas

Arm Solution

Engine Health Diagnostics through torsional vibration solution


Caterpillar make diesel engines


  • Repeated breakdowns on the 7 nos Caterpillar engines (Series 35 & 34) across the 11 land rigs
  • These breakdowns were impacting the drilling performance.
  • A local service provider advised Top End Overhaul on 3 nos. 3512 & some repair activities like injector replacement, turbocharger replacement, cylinder head replacements on the other engines.


  • Neptunus’ expert advised for Engine Health Diagnostics using torsional vibration analysis. The objective was to ascertain the problem & recommend the optimal servicing and spare parts to prevent the breakdowns.
  • Neptunus’ team went onboard & carried out the engine health inspection through torsional vibration tool
  • The report data showed that only one 3512 engine needed a Top End
    Overhaul & MTBO (Mean Time Between Overhauls) for the other two 3512 could be extended by 2000 hours with minor repairs. The other engines could be repaired only replacing the specific faulty components like injectors, turbo cartridges, dampers & by doing the calibration of fuel pumps
  • Neptunus’ team proposed an optimized list of spare parts which had fewer parts than the estimate of the local service provider. The job was completed by Neptunus on time and since then, these engines have been running without breakdown.


  • Since MTBO was extended by 2000 hours (20% extension), life cycle cost was reduced by (⅕)*$50,000 per engine = $10,000 per engine, resulting in savings of $20,000 for two engines.
  • The repair saved 10 days compared to overhaul, and breakdowns were completely eliminated.
  • The drilling performance improved. Rigs were able to complete wells on time & the charterer extended the contract of one rig by a period of 6 months .This enabled revenue of 180 days * $5,000 = $900,000
