Vibration Condition Monitoring Solution
What Is Vibration Condition Monitoring?
Vibration monitoring is a technique that uses speed sensors to measure and analyze vibration levels, which are characterized by variations in amplitude, intensity, and frequency, to identify defects. These sensors detect the rotation and magnetic fields of the machines and analyze the resulting data to detect any unusual vibration patterns or frequencies that may indicate potential issues. By monitoring machine vibrations, it is possible to optimize their performance and prolong their lifespan.
In simple terms, a vibration condition monitoring system is a tool used to monitor the health of rotating machines like engines, shafts, etc. by measuring their vibration patterns. By detecting any changes in these vibrations, the system can alert operators or maintenance personnel about potential problems before they become serious.
The Importance of Vibration Condition Monitoring
Analyzing Vibration Data To Detect Issues
By analyzing the vibration monitoring data, it is possible to detect patterns that may indicate potential issues with the machinery. This can help identify problems early before they escalate and result in machine failure. Read more
Detecting Mechanical Specific Defects
This approach is particularly effective in detecting mechanical defects such as misalignment, friction, and bearing wear. . Read more
Especially Used For Rotating Machinery
Vibration monitoring is essential in industries such as marine, oil & gas , where rotating machinery like engines, gearboxes, motors, bearings, and shafts are used. By monitoring the vibration levels of the machinery, it helps ensure that the equipment is operating as intended. Read more
Part of a Predictive Maintenance Strategy
This technique is a key tool in predictive maintenance, where maintenance activities are scheduled based on the results of the vibration analysis. By addressing potential issues before they become significant problems, this strategy can help lower maintenance costs and extend the life of the equipment. Read more
A Typical Process of How Vibration Monitoring is Carried Out In The Industry
Step 1: Determine the Expected Vibration Profile
Creating a model of the equipment's expected vibration profile based on its design and specifications enables you to identify and distinguish normal vibrations from abnormal ones.
Step 3: Convert the Analog Signal to Digital
Converting the analog vibration signal into a digital format is necessary for processing and analyzing the data accurately.
Step 5: Analyze Harmonic Frequencies
Analyzing the harmonic frequencies that are multiples of the fundamental frequency can provide insights into issues related to the rotation of the equipment's components.
Step 7: Phase Analysis
Phase analysis helps to determine the location of vibration sources in relation to the equipment's components and can be used in conjunction with frequency and time-waveform analysis.
Step 9 : Analyze Synchronous, Asynchronous, and
Sub-Synchronous Frequencies
Categorizing the vibration frequencies into synchronous, asynchronous, and sub-synchronous can help to identify the root cause of the problem in the equipment
Step 2: Establish a Benchmark
Having a benchmark vibration profile is crucial to detecting changes in the equipment's behavior over time and identifying potential problems before they lead to equipment failure.
Step 4: Convert Time Domain to Frequency
Domain
By using the Fast Fourier Transform (FFT) algorithm to convert the time domain signal to a frequency domain signal, you can identify frequency spikes that correspond to specific physical characteristics of the equipment.
Step 6: Time-Waveform Analysis
Time-domain analysis provides additional insights into equipment vibration patterns, especially for low-speed applications.
Step 8 : Separate Steady-state and Transient
Signals
Separating steady-state signals from transient signals can help to identify patterns in the vibration data that are indicative of underlying issues.
Step 10: Evaluate Equipment Condition
and Performance
Vibration analysis can provide quantitative measurements of equipment condition and performance, enabling you to detect issues such as bearing wear, misalignment, or unbalanced components that could lead to equipment failure.
Step 1: Determine the Expected
Vibration Profile
Creating a model of the equipment's expected vibration profile based on its design and specifications enables you to identify and distinguish normal vibrations from abnormal ones.
Step 2: Establish a Benchmark
Having a benchmark vibration profile is crucial to detecting changes in the equipment's behavior over time and identifying potential problems before they lead to equipment failure.
Step 3: Convert the Analog
Signal toDigital
Converting the analog vibration signal into a digital format is necessary for processing and analyzing the data accurately.
Step 4: Convert Time Domain to
Frequency Domain
By using the Fast Fourier Transform (FFT) algorithm to convert the time domain signal to a frequency domain signal, you can identify frequency spikes that correspond to specific physical characteristics of the equipment.
Step 5: Analyze Harmonic
Frequencies
Analyzing the harmonic frequencies that are multiples of the fundamental frequency can provide insights into issues related to the rotation of the equipment's components.
Step 6: Time-Waveform
Analysis
Time-domain analysis provides additional insights into equipment vibration patterns, especially for low-speed applications.
Step 7: Phase Analysis
Phase analysis helps to determine the location of vibration sources in relation to the equipment's components and can be used in conjunction with frequency and time-waveform analysis.
Step 8 : Separate Steady-state
and Transient Signals
Separating steady-state signals from transient signals can help to identify patterns in the vibration data that are indicative of underlying issues.
Step 9 : Analyze Synchronous,
Frequencies
Categorizing the vibration frequencies into synchronous, asynchronous, and sub-synchronous can help to identify the root cause of the problem in the equipment
Step 10: Evaluate Equipment
Condition and Performance
Vibration analysis can provide quantitative measurements of equipment condition and performance, enabling you to detect issues such as bearing wear, misalignment, or unbalanced components that could lead to equipment failure.
Vibration Condition Monitoring Using Torsional Vibration at Neptunus
Neptunus uses a vibration condition monitoring solution that is based on torsional vibration technology. This advanced technology allows us to monitor the health of machines in real-time, detecting faults at an early stage and providing sufficient time to design a maintenance schedule.
However, what sets us apart from other vibration monitoring systems in the industry are the following few key features that we offer:
Usage of Torsional Vibration
It is highly sensitive to small variations in rotational speed or torque, providing an early indication of problems. It offers a comprehensive analysis of the entire rotational system, enabling a detailed understanding of sources of vibration and potential issues. Torsional vibration is a flexible technique that can be used in a wide range of applications and industries. Read more
Simple
Setup
Our setup requires only 1 MPU sensor as compared to 12 sensors used in other condition-based monitoring setups, resulting in savings on the initial setup cost. Read more
Non- invasive
Sensors
Our setup involves a sensor with a once- in-a-lifetime calibration i.e., unlimited life with the same accuracy, whereas for others, the setup requires the sensors to be mounted to the equipment being monitored. Read more
No Prerequisite of
Historical Data
It is an in-situ solution that doesn’t require historical or baseline data to predict emerging faults. Read more
Most
Accurate
The accuracy of the product has been tested and validated by the likes of Indian defense organizations such as the Indian Navy, Air Force, Coast Guard, and other prestigious companies in the marine, oil and gas, industrial, locomotive, and energy sectors. . Read more
IRS “Class Approved” System
Our engine condition
monitoring system based on torsional vibrations is the first condition monitoring system in the world to be class approved. It is “Class Approved” by IRS (Indian Register of Shipping).
Read more
Usage of Torsional Vibration
It is highly sensitive to small variations in
rotational speed or torque, providing an early indication of problems. It offers a comprehensive analysis of the entire rotational system, enabling a detailed understanding of sources of vibration and potential issues. Torsional vibration is a flexible technique that can be used in a wide range of applications and industries.
Read more
Simple
Setup
Our setup requires only 1 MPU sensor
as compared to 12 sensors used in other condition-based monitoring setups, resulting in savings on the initial setup cost.
Read more
Non- invasive
Sensors
Our setup involves a sensor with a
once- in-a-lifetime calibration i.e., unlimited life with the same accuracy, whereas for others, the setup requires the sensors to be mounted to the equipment being monitored.
Read more
No Prerequisite of
Historical Data
It is an in-situ solution that doesn’t
require historical or baseline data to predict emerging faults.
Read more
Most
Accurate
The accuracy of the product has been
tested and validated by the likes of Indian defense organizations such as the Indian Navy, Air Force, Coast Guard, and other prestigious companies in the marine, oil and gas, industrial, locomotive, and energy sectors.
.
Read more
IRS “Class Approved” System
Our engine condition
monitoring system based on torsional vibrations is the first condition monitoring system in the world to be class approved. It is “Class Approved” by IRS (Indian Register of Shipping).
Read more
Vibration Condition Monitoring Solution Offered By Neptunus
Engine condition monitoring system
Engine condition monitoring system is an advanced, class-approved technology that identifies existing and emerging faults months in advance, giving enough time to prevent any catastrophic unplanned breakdown
Why Choose The Torsional Vibration Condition Monitoring Method Over The Traditional Linear Vibration Method?
Linear Vibration | Torsional Vibration | |
---|---|---|
Definition | Movement or mechanical oscillation about an equilibrium position of a machine or component | Changes in the relative angular displacement between two points on a rotating shaft |
Sensor | Lateral vibration can be measured mostly using accelerometers | Torsional vibration can be monitored using a sensor such as an MPU, speed sensor, and encoder |
Sensor location | Very critical parameter. If the site is wrong, there will be lots of false alarms | The sensor is positioned on the rotating shaft |
Repeatability/ Calibration | Often require sensor calibration to ensure accurate and repeatable results | This technique comes with a sensor with a once-in-a-lifetime calibration. i.e., unlimited life with the same accuracy |
Summary | The measurement of lateral vibrations is an indirect measurement of the forces on the component that could fail. | The measurement of torsional vibrations is a direct measurement of the forces on the component that could fail. |
Why Choose Neptunus?
Neptunus Power Plant Services Pvt. Ltd (founded on 24th June 1996) has 25+ years of experience in maintenance and reliability solutions for oil & gas, marine, industrial, and defence asset users across South Asia, the Middle East, Africa, and Europe.
The vibration monitoring system is one of the most important parts of asset reliability management solutions and is used to minimize maintenance costs and reduce the risk of failure.
As vibration monitoring is used to identify faults in machines, in a similar way, we address the need for a real-time oil equipment monitoring system to deliver immediate insights into oil health, ensuring the seamless operation of your assets.
